FTTH GJYXCH GJYXFCH G652D G657A1 A2 Singlemode Fiber Drop Cable FTTH Cable 1 2 4 Core Fiber Optic Cable
Produktdetails:
| Herkunftsort: | CHINA |
| Markenname: | TTI Fiber |
| Zertifizierung: | ISO 9001, ISO 14001, REACH， ROHS, CE and CPR certificates |
| Modellnummer: | GJYXCH Glasfaserkabel |
Zahlung und Versand AGB:
| Min Bestellmenge: | 1000 |
|---|---|
| Preis: | verhandelbar |
| Verpackung Informationen: | Standardpaket (Surport OEM/ODM) |
| Lieferzeit: | 5-8 Arbeitstage |
| Zahlungsbedingungen: | D/A, D/P, T/T... |
| Versorgungsmaterial-Fähigkeit: | 100000 Meter |
|
Detailinformationen |
|||
| Produktname: | GJYXCH Glasfaserkabel | Anwendung: | Outdoor -Glasfaserkabel |
|---|---|---|---|
| Farbe: | Schwarz | Material: | LSZH PE |
| Fasertyp: | G652D G657A1 G657A2 | Zertifizierung: | ROHS,CE,ISO14001,ISO9001 |
| Verwenden: | Fttx | Länge: | Customizted |
| Qualitätskontrolle: | 100% Test vor dem Versand | Paket: | Hölzerner Ram |
| Hervorheben: | FTTH singlemode fiber drop cable,G652D fiber optic cable,4 core FTTH cable with warranty |
||
Produkt-Beschreibung
FTTH GJYXCH GJYXFCH G652D G657A1 A2 Singlemode Fiber Drop Cable FTTH Cable 1 2 4 Core Fiber Optic Cable
Indoor Outdoor FTTH G657A2 GJYXFCH 1KM Outdoor Fiber Optic Drop Cable
GJYXCH Drop Cable Construction / Cross Sectional Diagram
Technical Specification
| Items | Specification |
|---|---|
| Fiber count | 1/2/4F |
| Fiber | Out diameter(±5μm): 250 |
| Outer sheath |
Self supporting element: 1.0mm Steel wire Tensile element: 2*0.4mm Steel wires Sheath material: LSZH Color: Black |
| Out diameter | 5.1(±0.2)*2.0(±0.1) mm |
| Cable weight(kg/km) | 22 |
Optical Fiber Specifications
| Fiber type | G652D (1310/1550nm) | G657A1 (1310/1550nm) | G657A2 (1310/1550nm) |
|---|---|---|---|
| Attenuation |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
Typical: 0.36/0.22 Maximum: 0.5/0.4 |
| Zero Dispersion Slope | ≤0.091 ps/km*nm2 | ≤0.092 ps/km*nm2 | ≤0.092 ps/km*nm2 |
| Dispersion(1285~1340nm) | -3.5 - 3.5ps/(nm*km) | -3.5 - 3.5ps/(nm*km) | -3.5 - 3.5ps/(nm*km) |
| Mode field Diameter(@1300nm) | 9.3±0.4 µm | 8.8±0.4 µm | 8.8±0.4 µm |
| Cutoff wavelength cable(nm) | ≤1260 nm | ≤1260 nm | ≤1260 nm |
| Min bend radius(mm) | 16 mm | 10 mm | 7.5 mm |
| Cladding diameter(µm) | 125±1.0 | 125±1.0 | 125±1.0 |
Mechanical and Environmental Performance of the Cable
| Mechanical properties | Installation | Operation |
|---|---|---|
| Tensile strength | 300N | 600N |
| Min bend radius | 15mm | 30mm |
| Crush resistance | 2000N/100mm | |
The mechanical properties of other optical fibers and cables shall meet international standards of IEC 60794.
Fiber Optical Cable Temperature Specifications
| Transportation temperature | -20℃~+60℃ |
| Storage temperature | -20℃~+60℃ |
| Installation temperature | -20℃~+60℃ |
| Operation temperature | -20℃~+60℃ |
